The Mean Well MW-EDR-120-48 is a compact and economical 120W single-output industrial DIN rail power supply, featuring a slim 40mm width for space-saving installations. It accepts a universal AC input range of 90~264VAC and delivers a regulated 48VDC output at 2.5A, incorporating protections against short circuit, overload, overvoltage, and over temperature. This reliable power supply is cooled by free air convection, can be mounted on TS-35/7.5 or TS-35/15 DIN rails, and is certified for industrial control equipment (UL508) and industrial immunity (EN61000-6-2), making it suitable for various industrial applications.

Key Features

• Wide Input Range: 90–264V AC universal input.
• Industrial Grade: UL508 and EN62368-1 certified.
• Compact Form Factor: 40 mm slim width for DIN rail TS-35/7.5 or 35/15 mounting.
• High Efficiency: Up to 88.5% with convection cooling.
• Robust Protection: Short circuit, overload (constant current mode), over-voltage, and over-temperature.
